Draconis large caliber centrifugal pump features compact inline structure for effortless installation, paired with lightweight streamlined design to deliver long-term reliable service life. Equipped with anti-rust treated stainless steel pump casing, copper impeller and AISI304 stainless steel shaft, together with high-temperature corrosion-resistant mechanical seal and Class-F insulated copper wire motor, it handles clean water within 0–90℃. This pump is widely applied in heating circulation, air conditioning, industrial circulation and large-flow water supply boosting projects.
| Model | large caliber centrifugal pump |
| Powersource | 220V50HZ/380V50HZ |
| Power | 1.1-2.2KW |
| Approved fluids | Clean water |
| Max flow | 28-80m3/h |
| Max head | 16-23m |
| Rated flow | 21-42m3/h |
| Rated head | 11-18m |
| Inlet/Outlet range | DN50-DN100 |
| Casing | Stainless steel casting with salt spray electrophoresis and rust resistance |
| Impeller | Copper |
| Shaft | SS304 |
large caliber centrifugal pump
